CNC Stainless Steel Water Chiller Laser Cutting Machine

CNC Stainless Steel Water Chiller Laser Cutting Machine

Fiber Laser Cutting Machines are widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters... Send Inquiry
Product Details



Quick Details
Application:Laser CuttingCondition:NewLaser Type:Fiber Laser

Applicable

Material:

Metal

Cutting

Thickness:

0-30mmCutting Area:1500*3000mm

Cutting

Speed:

25m/minCNC or Not:Yes

Cooling

Mode:

Water Cooling

Control

Software:

DG
Graphic Format Supported:AI, DXF, PLT

Place of

 Origin:

China (Mainland)
Brand Name:EO

Model

 Number:

F3015Certification:CE, ISO, SGS
After-sales Service Provided:Engineers available to service machinery overseas

The Max

 capacity:

800KGWeight:5200KG

Min line

width:

0.1MM

Power Requirements:

380V/50Hz/16ALaser Head:Genius Auto Focus Laser Head
Component:France Schneider Electronic ComponentMotor:Japan Yaskawa Servo Motor

Bearing

 housing:

Japan NSK

 Bearings

Laser source:IPG or MAXPHOTONICSGear pump:Auto lubrication system





1.Cast iron bed

Integrally formed, reject splicing

Using flake graphite cast iron, the lowest tensile strength of which is 200MPa. High carbon content, high compressive strength and high hardness. Strong shock absorption and wear resistance. Good casting and cutting performance. Excellent lubricity, corrosion resistance and dimensional stability. Low thermal sensitivity and bed gap sensitivity reduce the loss of equipment in using, so the machine accuracy could maintain for a long time, and no deformation in a life cycle.


2.Auto focus laser head

Free your hands, enjoy auto focus

(1)Auto-focus

Applicable to various focal lengths, which are controlled by machine tool control system. Focal point will be automatically adjusted in cutting process to achieve the best cutting effect of different thicknesses sheets metal.

(2)Free

Focal length is controlled by operating system. We don’t need to do manual regulation,which effectively avoids errors or faults caused by manual operation.

(3)Fast

It can automatically adjust the most appropriate focal points in working process, greatly improving cutting speed;

When replacing different materials or different thicknesses sheet, manual focus laser head needs to adjust focal length manually, very inefficient; auto focus laser head can read system storage parameters automatically, very efficient;

(4)Accuracy

Increasing perforation focus length, separately setting perforation focal length and cutting focal length, enhance cutting accuracy.

(5)Durable

Built-in double water-cooling structures can ensure constant temperature of collimating and focusing components, avoid lenses overheating and extend service life of lenses.

Increasing collimation protective lens and focus protective lens, carefully protect key components.



3.Operating system display

Elegant appearance curve

The first one to use UI design in the world which lets display respond to processing table, making processing more intuitive. Elegant curves precisely fit machine body. Strong waterproof breathable system creates the best space, making operation more convenient. Diamond cutting process and HD plasma tempered glass make screen more exquisite and comfortable to use.


4.Cast aluminum crossbeam

Integral steel mold pressure casting, light, flexible and efficient

After artificial aging, solution treatment and finishing, crossbeam owns good integrity, rigidity, surface quality, toughness and ductility. Aluminum alloy’s metal characteristics of light weight and strong rigidity are helpful to high speed movement in processing, and high flexibility is beneficial to high-speed cutting of various graphics based on high accuracy. Light crossbeam can give equipment a high operation speed, improving processing efficiency to ensure processing quality.


5.Appearance design

Aesthetics was introduced to industrial ID, perfect combination of technology and aesthetics

Powerful hockey stick shaped decorations adopt black acrylic with thickness of 30mm, ice film drawbench silver design of the same car and alpine white sheet metal, the international design style is accepted by global consumer groups.

With precise cast iron bed, the whole machine is as firm as a rock. The most reasonable golden ratio and the greatest parts layout make the whole machine more stable, comfortable, accurate, and technological.

PC head capsule design through vacuum hot deformation processing makes Z axis so light.

Crossbeam adopts ribbon design elements, giving crossbeam limitless velocity space.


NO.2 Machine Application Field

1.Application Materials: Fiber Laser Cutting Equipment is suitable for metal cutting with Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring Steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc

2.Application Industries: Fiber Laser Cutting Machines are widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts, Nameplates, etc.


Our Service

Spot delivery, including delivering small batches of goods

Provide wide-range and complete materials series products

Cutting plates, including complex shapes of materials and special processing and disposal

Cutting bars and strips

Our application technology expert provide the best material and recommendation

One-stop service
