Glass CO2 Laser Marking Machine

Glass CO2 Laser Marking Machine

Product Name: Glass CO2 Laser Marking Machine
Classification: CO2 Laser Marking Machine
Application: non-metal materials
Place Of Origin: China
... Send Inquiry
Product Details

Product Parameters


Model

RF-CO2-30W

Laser tube

SYNRAD Firestar vi30 RF metal laser tube

Output power

30W

Mode quality

M2≤1.2

Ellipticity

<1.2

Rise time

<100µsec

Beam diameter

2.5+/- 0.5mm

Beam divergence

<7.0mRad

laser wavelength

10.57_10.63µm

Cooling

Air

mark line width

0.2mm

marking field for options

100mmx100mm/175mm x 175mm/200x200mm/300*300mm

marking speed

2m/s

Positioning speed

10m/s

minimum character

0.9mm

repeating orientation precision

±0.01mm

average power consumption

<1.3kw

power supply

220v/50Hz ,110v/60Hz

Package dimension

90*80*160cm

Gross weight

150kgs



Product Application

1.jpg Applicable materials:

Suitable for wood, paper, leather, cloth, plexiglass, epoxy, acrylic, unsaturated polyester resin and other non-metal materials.

1.jpg Applicable industries:

Widely used in leather, food, beverage, colth, electronic, meter, communication instruments,package and other industries, can be combined wiith streamline for online marking.


Product Features

1.jpg high reliability, long continuous operation time,clear and complete printing.

1.jpg Supported by rich software, enable to collect and manufacture various labels, nono-contact processing

1.jpg Ensure original precision of the surface of work piece to the maximum limit.

1.jpg Suitable for engraving on various materials,long time preser,simple installation and convenient

1.jpg The optical system is fully sealed, it can prevent the dust the entering laser body and reduce the equipment failure rate.


More

Our Services:

Pre-sale services: enthusiasm

We provide you with the process plan, process flow design and manufacturer equipment according to your special demand.

Sale services: servant

Send technicians to the job site for guiding the installation and adjustment of Glass CO2 Laser Marking Machine, training operators and finishing the check and accept together with you.

After-sale services: faithfulness

To establish long term friendship, we will regularly pay return visit to customers.
