Infrared Ray Stone Laser Cutting Machine

Product Name: Infrared Ray Stone Laser Cutting Machine
Classification: Stone Laser Cutting Machine
Application: galvanized sheet, electrolytic plate, aluminum plate, etc
Place Of Origin: China
... Send Inquiry
Product Details

Infrared Ray Stone Laser Cutting Machine adopts PLC programmable control system, man-machine integration of touch screen operation interface, with high precision rotary encoder and the infrared liner, cutting left and right adopts the frequency converter to control the speed, speed can be adjusted according to the stone material, lift up and down adopts hydraulic, the high speed moving parts adopt imported high quality spare parts, so it cutting with high efficiency,  especially suitable for the high value of large specifications of granite, marble slabs cutting.


Product Parameters


TYPE



FRT-450

Blade diameter

mm

φ350- φ500

Max.working dimensions(LxWxH)

mm

3200x3200x100

Table size(LxW)

mm

3200x2000

Workbench tilting degree

0°-85°

Workbench rotating degree

0°-90°+45°/0°-45°-90°-360°

Main motor power

kw

15

Gross power

kw

20.2

Water consumption

m3/h

3.5

Trolley dimension(LxWxH)

mm

6000x5000x2600

The total weight

kg

5200


Product Features

1.jpg high cutting precision

1.jpg high stability

1.jpg easy and flexible operation


More

Our Services:

Pre-sale services: enthusiasm

We provide you with the process plan, process flow design and manufacturer equipment according to your special demand.

Sale services: servant

Send technicians to the job site for guiding the installation and adjustment of Infrared Ray Stone Laser Cutting Machine, training operators and finishing the check and accept together with you.

After-sale services: faithfulness

To establish long term friendship, we will regularly pay return visit to customers.
