LB-MC series CO2 laser engraving machine adopted with advanced CO2 RF laser device and high stale laser power, and equipped with high quality optical elements, automatic control system driver and high-speed scanning galvanometer system....
Send Inquiry| Product Details | |
| Place of Origin: | China |
| Brand Name: | USA Synrad Laser |
| Certification: | CE |
| Model Number: | LB-MC30 |
| Detailed Product Description | |||
| Laser Power: | 30W | Laser Source: | Synrad CO2 |
| Laser Wavelength: | 10640nm | Pulse Frequency: | ≤50KHz |
| Engraving Area: | 70x70mm ~300x300mm | Cooling System: | Air-cooling |
| Power Supply: | 220V / 50Hz | Power Consumption: | 0.8KW |
| Laser Materials: | Wood Paper Bamboo PU Leather Plastic Acrylic Glass | ||
Marking
Advanced processing mode, a high degree of precision
Easy product identification.
Environmental friendly.
Low cost, fully automatic, Easy operation.
Permanent & Long Lasting.
| Specifications | |||
| Model | MCF10 | MCF30 | MCF60 |
| Laser Power | 10W | 30W | 60W |
| Laser wavelength | 10640nm | 10640nm | 10640nm |
| Highest feeding speed | 300m/min | 300m/min | 300m/min |
| Marking | Can mark on stationary or moving parts | ||
| Software | automatic encoding, variable text, date, serial number, lot number, bar code and two-dimensional code printing, and can be modified according to customers ' different needs of production line flexibly. | ||
| Adjustable lift range | 0~1000mm or custom design | ||
| Power consumption | ≤600W | ≤800W | ≤2KW |
| Power supply requirement | 220v/50HZ | 220v/50HZ | 220v/50HZ |
| Technical Parameters | |||
| Model | LB-MC10 | LB-MC30 | LB-MC60 |
| Laser Power | 0~10w | 0~30w | 0~60w |
| Laser wavelength | 10640nm | 10640nm | 10640nm |
| Pulse frequency | ≤50kHZ | ≤50kHZ | ≤50kHZ |
| Working area | 70X70mm,110×110mm (optional) | 110X110mm,140×140mm (optional) | 175X175mm,250×250mm (optional) |
| Marking speed | ≤7000mm/s | ≤7000mm/s | ≤7000mm/s |
| minimum line width | 0.04mm | 0.05mm | 0.06mm |
| Repeated precision | ±0.003mm | ±0.003mm | ±0.003mm |
| Cooling system | air-cooled | air-cooled | air-cooled |
| Power supply | AC220V/50HZ | AC220V/50HZ | AC220V/50HZ |
| power consumption | ≤0.5KW | ≤0.8KW | ≤2KW |
| Dimension | 820mm×620mm×1360mm | 860mm×620mm×1360mm | 1200mm×620mm×1500mm |
Standard Accessories (CO2 Laser Engraving Machine)
A set of USA SYNRAD Laser Source
A set of Galvo tech Scanner
A set of focus lens
A set of high-speed vibrating mirrors
A set of marking control system (Original version)
An industrial computer
A marking work table
A red laser pointer
A pedal switch
A set of marking software
Our Service
Spot delivery, including delivering small batches of goods
Provide wide-range and complete materials series products
Cutting plates, including complex shapes of materials and special processing and disposal
Cutting bars and strips
Our application technology expert provide the best material and recommendation
One-stop service
