Stainless Steel Laser Marking Machine

IPG Germany Fiber Laser Marking Machine

IPG Germany Fiber Laser Marking Machine

IPG Germany Fiber Laser Marking Machine Mobile (Cover,battery,keyboard, I Phone Case)Jewellery(Ring,pedeant,bracelet),eyeglass,clocks and craft.... Send Inquiry
Product Details



Technical Parameter:
ModelGW-10 / 20 / 30 / 50
Laser device

Gernmany IPG fiber laser device,

Lifetime >100,000 hours

Optical maser wavelength1064nm
Average output power10W / 20W / 30W /  50W
Beam Radiation Angle≤2mrad
Modulation frequency range20KHz~80KHz
Beam QualityM2:1.2-1.8
Working EnvironmentClean and dust free or dust less
Marking Depth0-1mm(depending on the materials)
Maximum speed8000mm/s
Resolution0.001mm
Repeat location accuracy0.003mm
Marking rangeF=160mm,160×160mm
Working range182mm x (±2mm)
Working stability (8h)<±1%rms
Minimum line width30um
Minimum character height0.2mm
Sheet label marking time≤ 90 s (depend on the content)
Laser power supply<500W / 220V / 50Hz,
Cooling modeAir cooled
The Max input power2 phase 220V AC,50Hz,about 2.5A
Environmental Requirement0~35°C,humidity≤90%
Graphic Format Supportedbmp,jpg,gif,tga,ai,dxf,dst,plt,etc.
Warranty2 year, within time free change parts
PackageWooden case
Delivery time5 working days
Packing size1000*1200*1600mm
G.W20kg--60kgs
Configurations:
1. IPG 20W laser source2. IPG control board & control system
3. 17inch computer4. Golden Orange software




Optioanl

Germany Scanlab + USD3600;

Rotary diameter 80mm + USD300

Machine Features:

1.German IPG fiber laser ,servicetime 100,000 hours.

2.High speed galvo scanner German

3.Easy Operate without route maintenance

4.Higher precision,faster speed

5.Air cooling, Small size,low power consumption

6.Red light preview: show the marking position before lasering

7.Up and Down Lifter laser head(desktop) and up and down worktable

easy to marking engraving different workpiece

8.Rotary attachment optional

Engrave and mark inside and outside ring jewellery

9.High temperature resistance

perfect for marking medical equipment etc that requires sterilization

10.The durability & Finer Marking quality

optimizes it for use in jewelry, mobile phones, and other items of value.

11.Computer Installed with Free Powerful software10.

User friendly interface, easy operation set and deal different layers graphic in separate Support PLT,PCX, AL, DXF, BMP,JPG formats file compatible AutoCAD, CorelDraw, Photoshop etc software Automatic serialization, date coding letter, symbol, pattern, figure, image, bar code, 2D code auto arrangement and amendment

Germany IPG Fiber Laser Metal Marking Machine:

· Many type of metals: Gold,Silver,Stainless Steel,Copper,

Aluminum,chrome Brass,etc

· Alloy and metal oxides: Anodized Aluminum

· Some non-metallic materials & Special surface treatment:silicon wafer,ceramics,plastic,rubber,epoxy resin,ABS,Printing ink,Plating,Spraying,Coating film

Fiber Laser Marking Machine:

· Electrical Engineering and Electrical part and component

· Mobile (Cover,battery,keyboard, I Phone Case)

· Jewellery(Ring,pedeant,bracelet),eyeglass,clocks and craft

· Building materials,PVC pipe

· Car motor car spare part

· Insturment and meters and cutting tool

· plastic case

· aviation and aerospace,

· military product,

· hardware fitting and accessory

· sanitary appliance

· stationery

· food and beverage

· Medicine package and medical instrument

· solar Pv industry


Our Service

Spot delivery, including delivering small batches of goods

Provide wide-range and complete materials series products

Cutting plates, including complex shapes of materials and special processing and disposal

Cutting bars and strips

Our application technology expert provide the best material and recommendation

One-stop service
