Stainless Steel Laser Welding Machine

Metal Letter Welding Machine

Metal Letter Welding Machine

Product Name: Mini Portable Fiber Laser Marking Machine
Classification: Fiber Laser Marking Machine
Application: Metal, Plywood, Wood, etc.
Place Of Origin: China
... Send InquiryChat Now
Product Details

Product Parameters



model

EO-W150

EO-W200

Maximum laser power

150W

200W

Laser wavelength

1064nm

Laser power supply

6KW

9KW

Laser welding minimum capacity pool

0.1mm

Laser pulse frequency

≤50Hz

Laser pulse width

≤20ms

Spot adjustment range

0.1~3.0mm

The spot size

0.2~3.0mm

Protective gas

1 way

electricity demand

220V single phase/50Hz/20A

Dimensions of the system

Host system

1000×480×1080mm

cooling system

720×510×970mm

net weight

115KG







Product Advantages


1.jpg Energy, pulse width, frequency, spot size, etc. can be adjusted in a larger range to achieve a variety of welding results. Parameters from the closed chamber control rod adjustment, simple and efficient

1.jpg Adopting imported ceramic condenser cavity, corrosion resistance, high temperature, high efficiency of photoelectric conversion, life span of concentrating cavity (8-10 years), life of xenon lamp of the laser spot welding machine are all more than 8 million times

1.jpgThe use of the world's most advanced automatic shading system, eliminating the time in the work of the eye irritation

More

Our Services:

Pre-sale services: enthusiasm

We provide you with the process plan, process flow design and manufacturerMini Metal Letter Welding Machine according to your special demand.

Sale services: servant

Send technicians to the job site for guiding the installation and adjustment of Metal Letter Welding Machine, training operators and finishing the check and accept together with you.
